MULTI-PURPOSE & LIGHTWEIGHT
Galaxy Trident T10 is a large-format, commercially built RIB workboat developed for high-capacity operations across defence, enforcement, rescue, commercial and offshore transport. With increased internal volume and deck space, it supports up to 12 passengers plus 2 crew, making it ideally suited to crew transfer, sea safari, and passenger-carrying roles. The Trident T10 features a removable D-collar system for ease of maintenance and maximised usable space, with a solid foam collar option for extreme durability. Built on a soft-riding deep-vee hull combined with shock mitigation seating, it provides excellent crew comfort and safety. The hull is constructed from circular and fully recyclable marine-grade aluminium, and a modular track system allows for adaptable deck layouts. Shelter options, including a micro cabin and full cabin, are available, making the Trident T10 a flexible and mission-ready platform for professional operators.
SPECIFICATIONS
Total Length
960 cm / 31′ 6”
Cockpit Length
650 cm / 21′ 4”
Overall Width
320 cm / 10′ 6”
Cockpit Width
220 cm / 7′ 3”
Tube Diameter Max
62 cm / 24,4”
Weight of the Vessel
2000 kg / 4400 lbs
Cargo Carrying Capacity
2200 kg / 4840 lbs
Passenger Capacity
16
Number of Compartments in Tubes
7 / –
Recommended Engine Power
600 HP / 441,3 kW
Maximum Engine Power
700 HP / 514,8 kW
Maximum Motor Weight
800 kg / 1760 lbs
Motor Leg Length
2×30″
Fuel Tank Capacity
1000 L
Material of D-Collar: Hypalon Inflatable / TPU Foam
Material of Tubes
Hull Material
Aluminum Hull RIB
Aluminum Sheet Thickness (side / bottom)
6mm
Boat Design Category
C, B
Inflatable D-shaped tubes are ideal for rescue equipment and boats due to their lightness and compactness. D-shaped tubes have a round profile for even pressure distribution. They provide high buoyancy and improved stability on the water. Inflatable tubes are made from durable materials such as PVC or Hypalon.
D-shaped foam tubes offer additional strength and durability due to their resistance to mechanical damage. D-shaped tubes have a flat inner side and a pounded outer side. This shape allows for more efficient use of space and provides greater stability. The protective coating prevents exposure to UV rays and chemicals, making these tubes ideal for use in extreme conditions.
Circular recyclable
D-Tube
Offshore commercial deep vee hull
High gunwale walls for safety
Aluminum hull, tough & repairable world-wide
Shock mitigation options
