MULTI-PURPOSE & LIGHTWEIGHT
Galaxy PILOT 10.0 is a large-format, commercially built RIB workboat designed for extended operations across patrol, rescue, commercial transport and offshore support. With capacity for 12 passengers plus 2 crew, it is equally suited to sea safari applications or crew transfer duties. Built on a deep-vee aluminium hull for excellent ride comfort, stability and durability, it features Hypalon inflatable tubes and a modular layout. Shelter options include an open deck, micro cabin or full cabin, offering flexibility for a wide range of operational profiles.
SPECIFICATIONS
Total Length
960 cm / 31′ 6”
Cockpit Length
650 cm / 21′ 4”
Overall Width
310 cm / 10′ 2”
Cockpit Width
186 cm / 6′ 1”
Tube Diameter Max
62 cm / 24,4”
Weight of the Vessel
1400 kg / 3080 lbs
Cargo Carrying Capacity
2300 kg / 5060 lbs
Passenger Capacity
16
Number of Compartments in Tubes
7
Recommended Engine Power
600 HP / 441,3 kW
Maximum Engine Power
700 HP / 514,8 kW
Maximum Motor Weight
800 kg / 1760 lbs
Motor Leg Length
30″ / 2×25″
Fuel Tank Capacity
600 L
Material of Tubes
HYPALON
Hull Material
Aluminum Hull RIB
Aluminum Sheet Thickness (side / bottom)
6mm
Boat Design Category
C, B
Circular recyclable
Hypalon tubes
Offshore commercial deep vee hull
Aluminum hull, tough & repairable world-wide
Customised
to your requirements
