MULTI-PURPOSE & LIGHTWEIGHT
Galaxy PILOT 12.0 is the next evolution in our range of heavy-duty, commercially built RIB workboats. Launching soon, this model is designed with a clear focus on cabin-equipped operations, offering both micro and full cabin options to suit a wide range of offshore, patrol, crew transfer, and commercial transport roles. With capacity for 12 passengers plus 2 crew, it is also ideally suited to sea safari and tourism applications. Built on a proven deep-vee aluminium hull with Hypalon tubes, the PILOT 12.0 will be available with varied power options to meet the specific needs of professional operators.
SPECIFICATIONS
Total Length
1160 cm / 38′ 1”
Cockpit Length
880 cm / 28′ 10”
Overall Width
310 cm / 10′ 2”
Cockpit Width
186 cm / 6′ 1”
Tube Diameter Max
62 cm / 24,4”
Weight of the Vessel
1600 kg / 3520 lbs
Cargo Carrying Capacity
2500 kg / 5500 lbs
Passenger Capacity
18
Number of Compartments in Tubes
7
Recommended Engine Power
700 HP / 514,8 kW
Maximum Engine Power
900 HP / 661,9 kW
Maximum Motor Weight
1000 kg / 2200 lbs
Motor Leg Length
30″ / 2×25″
Fuel Tank Capacity
1000 L
Material of Tubes
HYPALON
Hull Material
Aluminum Hull RIB
Aluminum Sheet Thickness (side / bottom)
6mm
Boat Design Category
C, B
Circular recyclable
Hypalon tubes
Offshore commercial deep vee hull
Aluminum hull, tough & repairable world-wide
Customised
to your requirements
